Custom CNC Milling Services For Your Idea
On Demand Manufacturing
- Rapid Processing to Shorten Delivery Cycle
- Easily Handle Complex Components
- Multiple Strict Quality Inspectionsy
CNC Milling Services Types
Milling equipment includes 3-axis, 4-axis and 5-axis. Each type of equipment has its own unique characteristics and scope of application:
3-axis
Unlock a new level of efficient production! 3-axis milling, precise carving of every detail, worry-free mass production, cost reduction, and efficiency soaring.
4-axis
One clamping, multi-faceted forming! 4-axis milling technology makes complex processing simple and efficient. Improve production flexibility, lower costs, and higher quality.
5-axis
5-axis milling is the ultimate weapon for complex surface processing. It combines precision and speed, provides excellent surface quality, and significantly shortens product development cycles.
Features of CNC Milling
CNC milling holds a pivotal position in modern manufacturing, renowned for its exceptional precision, versatility, repeatability, and broad application spectrum.
High precision
Because of the computer numerical control can precisely control the movement of the tool, CNC milling can achieve high-precision machining, often reaching micron-level accuracy.
Flexibility
Milling technology has highly flexibility.Not only can it quickly switch between different processing tasks, but also handle a variety of complex designs and materials easily.
Diversity
By changing tools and adjusting programs, CNC milling can process parts of different shapes and sizes, and is suitable for multi-variety, small-batch production.
Repeatability
During machining, the stability and uniformity of the CNC program guarantee adherence to preset standards and precision, fostering high repeatability in machining outcomes.
Highly automated
CNC milling machine tools can automatically complete complex processing operations, reducing reliance on manual operations and improving production efficiency.
CNC Milling materials
With the relentless progress of technology, the realm of precision processing and its applicability continue to expand. Each material possesses unique physical and mechanical characteristics, and RUIYI Model caters to this diversity by offering a wide array of milling services tailored to various materials.
*Metal: steel,stainless,aluminum,titanium,nickel alloy,magnesium,copper,polypropyle
*Non-metal: wood,glass,pvc,Polypropylene,nylon,polycarbona,fiberglass.
*Composite Materials: FRP(Fiber-reinforced plastics),Carbon fiber reinforced epoxy resin,Glass fiber reinforced aluminum
How CNC milling works
CNC Milling achieves efficient and precise processing of workpieces through preliminary preparation, workpiece clamping and positioning, automatic cutting, processing completion and subsequent processing.
Programming
First, the processing program needs to be written according to the design drawings of the parts. These programs usually use G code or M code to describe the cutting tools, cutting parameters, cutting paths, etc.Then,Transmit the written CNC program to the control system of the CNC machine tool.
Workpiece Clamping
Place the workpiece on the workbench of the CNC milling machine and clamp it firmly by using a fixture or clamp.Use positioning elements such as positioning pins to preliminarily position the workpiece.Use the fine-tuning device to adjust the position of the workpiece to the final processing position.
Execute Processing
The operator inputs the programmed machining program to the CNC controller.The controller reads and interprets the CNC code, generates control signals,and drives the various moving parts of the machine tool.CNC machine tools automatically plan and execute tool paths according to CNC program instructions.
Inspection
During the machining process, the CNC system monitors the position of the tool and workpiece, cutting force and other parameters in real time.If an abnormal situation is found (such as excessive cutting force, tool wear, etc.), the system will automatically adjust the cutting parameters or issue an alarm.
Post-processing
In order to improve the precision and surface quality of the processed parts and eliminate possible processing defects, we will perform correction, grinding or polishing on the processed parts.Measure the workpiece's size, shape, and surface roughness to verify compliance with requirements.
Tolerances for CNC Milling
We are fully aware of the importance of accuracy in the pursuit of manufacturing excellence. We proudly use the most advanced technology and are committed to achieving micron-level or higher processing accuracy to ensure that every product can meet or even exceed customers’ stringent requirements for accuracy, quality and efficiency.
| 3-Axis | 4-Axis | 5-Axis | |
| Maximum Part Size | 1000×500×500 mm | 1000×500×500 mm | 4000×1500×600 mm |
| Minimum Part Size | 5×5×5 mm | 5×5×5 mm | 5×5×5 mm |
| General Tolerances | ±0.1 mm | ±0.05 mm | ±0.1 mm |
| Lead Times | Delivery of simple parts can be as fast as 1 day. | 5 business days for most projects. | 5 business days for most projects. |
FAQ
What materials can be machined with CNC milling?
Common materials include metals (aluminum, steel, titanium, brass), plastics (ABS, nylon, PEEK), composites, and wood.
What types of parts can CNC milling produce?
CNC milling can create a wide range of parts, including prototypes, complex geometries, and high-precision components for industries like aerospace, automotive, and medical.
What are the tolerances achievable with CNC milling?
Tolerances as tight as ±0.001 inches (±0.025 mm) can be achieved, depending on the material, part design, and machine capabilities.
What is the maximum size of a part that can be milled?
The maximum size depends on the machine’s work envelope. Typical CNC milling machines can handle parts up to several feet in length, but specialized machines can handle even larger components.
How long does it take to complete a CNC milling project?
Lead times vary depending on part complexity, material availability, and order volume. Prototyping can take a few days, while larger production runs may require weeks.
What industries benefit from CNC milling services?
Industries such as aerospace, automotive, medical devices, consumer electronics, and industrial machinery rely heavily on CNC milling for precision components.
What are the advantages of CNC milling over traditional machining?
- High precision and repeatability.
- Ability to produce complex shapes.
- Faster production times for complex parts.
- Minimal manual intervention, reducing errors.
What file formats are required to start a CNC milling project?
Commonly accepted file formats include CAD files like STEP (.stp), IGES (.igs), and DXF (.dxf) for 2D designs.
Can CNC milling services handle low-volume and high-volume production?
Yes, CNC milling is versatile and can efficiently handle both low-volume prototypes and high-volume production runs.
